10 Spline SM465 to small bearing fig 8 NP205

10 Spline SM465 to small bearing fig 8 NP205

32 Spline GM 4x4 NV4500 to Fig 8 NP205 adapting kit

32 Spline GM 4x4 NV4500 to Fig 8 NP205 adapting kit

32 Spline SM465 to fig 8 NP205

NOTE SHORT 32 SPLINE INPUT IS NOT AVAILABLE AT THIS TIME

SKU
32 Spline SM465 to fig 8 NP205
Grouped product items
Product Name Qty
SM465 to NP205 adapter housing, '84 and older
$298.56
SM465 Adapter Spacer, for 32 Spline SM465 using old 10 Spline Adapter
$200.00
205/Short 32 Spline Input Conversion, Short 32 Spline Input Gear, Bearing, Snap Rings, Seal & Gasket kit
$250.00
Estimate Fees

Some things on this list you may or may not need but it is easy to remove them.



The first item is the adapter. This is needed to connect the transmission to the NP205

Next is the spacer, this is used to make up for the length of the stock 32 spline output on the SM465

If you dont have a short 32 spline male input for your NP205 we have one listed on this page.

To install the short 32 spline input in your NP205 it needs to be the larger 90mm input bearing. If you case does not have the 90mm input bearing (29,32 spline input cases), no problem we can bore your case for you! Just select the option and ship us your bare case. We will bore it out and ship it back.
